M290V QUATRO three-way T part

Not rated
€322,82 €266,79 excl. VAT
Delivered within 14 days​

Detailed information

Product detailed description

Four-point lattice construction of the M290 QUATRO Truss system, "V" variant designed for high loads. Thanks to its low weight, high variability and easy installation, it finds application in various uses, whether in theaters, music clubs, lecture halls, exhibition spaces, at concerts, during the construction of stages, etc.

  • designation: QTV35
  • length: 710 mm
  • width: 500 mm
  • weight: 9.6 kg
  • compatible with 200 / 400 / 500 / 600 series clamps
  • the possibility of another color according to the RAL swatch
  • material: aluminum alloy EN - AW 6082 T6
  • pipe diameter: 48 mm
  • tube thickness: 3 mm
  • diameter of braces: 16 mm
  • thickness of reinforcements: 2 mm
  • we deliver including connection pins

Additional parameters

Category: Truss construction for heavy loads - quatro
Weight: 9.6 kg
